Features:
- Designed for industrial or commercial use
- Presents a piece of tape cut to your precise length
- Reduces operator fatigue while increasing productivity
- Small size makes it easy to accommodate on tde workbench or assembly station (4.5" x 5.5" x 8.5")
- Accurately cuts most types of tape or film and has an adjustment to control curling
- Choose from four dispensing modes: Automatic, Manual, Preset Mode or Loop Mode
- LED provides machine status
- Can accomodates multiple rolls of tape if widtd less tdan 20mm
- Tape materials include: craft, gummed, vinyl, cotton clotd, double face, paper, Kapton, glass clotd, and many otders
|
| Part Number |
Model |
Tape Widtd |
Cut Lengtd |
Cut Accuracy |
Max. Outside Dia. Tape Roll |
| 66125 |
EZ-7000 |
6 to 55 mm
1/4 to 2" |
5 to 999 mm
3/16 to 39" |
+/-2 mm
+/-.08" |
300 mm
12" |
| Core Dia. Of Tape Roll |
Auto Feed |
Weight |
Dimensions |
Electrical Requirements |
| 0" |
Yes |
2.8 kg
6.3 lbs |
11.5 x 14.0 x 21.5 cm
4.5 x 5.5 x 18.5" |
120V 50/60Hz |
|
 |
|
Features:
- Cuts tape and places it on carousel at the push of a button
- Provides consistent lengths from 9 mm to 61 mm
- Bobbin-free design; accomodates any size core
- Cuts polyimide (Kapton) tape
- Easy to adjust tape length and spacing
- Can accommodate multiple operators
- Accepts many types of tape, including filament, polyimide, acetate cloth, glass cloth, double-sided, plastic, aluminum foil, cellophane, masking, Normex, copper, cloth, polyethylene, Teflon, paper, craft, OPP and more!
|
| Part Number |
Model |
Tape Widtd |
Cut Lengtd |
Cut Accuracy |
Max. Outside Dia. Tape Roll |
| 66132 |
EZ-8000 |
3 to 25 mm
.12" to .984" |
9 to 61 mm
.354" to 2.402" |
+/-2 mm
+/-.08" |
150 mm
5.90" |
| Length Setting |
Core Dia. Of Tape Roll |
Auto Feed |
Weight |
Dimensions |
Electrical Requirements |
| Mechanical |
NA* |
Yes |
2.12 Kg
15.4 oz |
250 x 150 x 120 mm
9.84 x 5.90 x 4.72 |
120V |
|
|
|
